Features
- Control Application
- 6-Way 2-Position Normally Closed
Auto Operation Type
-
Specification
- Working Media
- Air
- Port Connection Size
- IN & OUT Ports: 1/4″-18 NPT F
EX & Pilot Ports: 1/8”-27 NPT F
- Exterior Shape
- Circular Ø 38.1 mm (1 1/2 “)
- Pilot Pressure Range
- 40 – 110 PSI (2.76 – 7.58 bar)
- Max Working Pressure
- 300 PSI (20.7 bar)
- Temperature Range
- – 30°C to 120°C
Other Temperature Ranges available. Consult Factory
- Material (Valve Body)
- 316 L
- Net Weight
- 2.6 kg
- Seal Material
- Viton(FKM)
Other Seal Material are Available Upon Request
- Flow Rate
- Cv = 1.6
