Features
- Control Application
- 2-Way 2-Position, Normally Open
Adjustable Pilot Setting (Pilot Operated Spring
Return)
-
Specification
- Working Media
- Air
- Port Connection Size
- IN & OUT Ports : ¼”-18NPT F, Pilot Port : 1/8”-27NPT F
- Exterior Shape
- Circular Ø 38.1 mm (1 1/2 “)
- Pilot Pressure Range
- 30 – 120 PSI (2.06- 8.27 bar)
- Max Working Pressure
- 200 PSI (13.7 bar)
- Temperature Range
- – 30°C to 120°C
Other Temperature Ranges available. Consult Factory
- Material (Valve Body)
- 316 L
- Net Weight
- 750gm
- Seal Material
- Viton(FKM)
Other Seal Material are Available Upon Request
- Flow Rate
- Cv = 1.6
