Features
- Control Application
- 2-Way, 2-Position, Spring Biased Poppet Operated
Directional Flow (In the open position to allow forward flow and closed position to block reverse flow)
-
Specification
- Working Media
- Air
- Port Connection Size
- IN Port:OD1/4″Pipe
OUT Port: OD1/4″Pipe
- Exterior Shape
- Circular Ø25.0mm( 63/64″)
- Max Working Pressure
- 20,000PSI (1,378.9 bar)
- Temperature Range
- – 30°C to 120°C
Other Temperature Ranges available. Consult Factory
- Material (Valve Body)
- 316 L
- Net Weight
- 250 gm
- Seal Material
- Viton(FKM)
Other Seal Material are Available Upon Request
- Flow Rate
- Cv = 0.22
- Orifice Size (Standard)
- Ø2.6mm ( 7/64″)
- Cracking Pressure
- 1 to 3 PSI (0.068 to 0.206bar)
Other Cracking Pressure are Available Upon Request
