Features
- Control Application
- 2-Way, Needle and the Spring Biased Ball operated , Provides controlled flow in one direction (as arrow) and allows full flow in the opposite
-
Specification
- Working Media
- Oil
- Port Connection Size
- Input:3/8″-18NPT F
Output:3/8″-18NPT F
- Exterior Shape
- Circular Ø31.0 mm (1 7/32″)
- Max Working Pressure
- 10,000psi (689.4bar)
- Temperature Range
- – 30°C to 120°C
Other Temperature Ranges available. Consult
Factory
- Material (Valve Body)
- 316L
- Net Weight
- 540gm
- Seal Material
- Nitrile Rubber(NBR)
Other Seal Material are Available Upon Request
- Flow Rate
- Cv = 0.6
- Orifice Size (Standard)
- Ø 3.2 mm ( 1/8″)
- Options
- Body Material and end connections other option available upon request
