Features
- Control Application
- Directional Flow (In the open position to allow forward
flow and closed position to block reverse flow)
-
Specification
- Working Media
- Air
- Port Connection Size
- IN Port 1/2”-14NPT M,OUT Port 1/2”-14NPT F
- Exterior Shape
- Hexagon A/F 28.5MM (1 1/8″)
- Max Working Pressure
- 10,000psi(689.4 bar)
- Temperature Range
- – 30°C to 120°C
Other Temperature Ranges available. Consult Factory
- Material (Valve Body)
- 316 L
- Net Weight
- 180gm
- Seal Material
- Viton(FKM)
Other Seal Material are Available Upon Request
- Flow Rate
- Cv = 1.4
- Orifice Size (Standard)
- Ø5.0mm (13/64″)
- Cracking Pressure
- 1 to 3 PSI (0.068 to 0.206 bar)
Other Cracking Pressure are Available Upon Reques
